| Varenummer | C065VL01 V0 |
| Mærke | AUO |
| Størrelse | 6.5 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 550 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | C065VL01 V0 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 143.4×79.2 mm |
| omrids | 157.2×89.2 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 550 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 55/55/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 80 pins |
| indgangsspænding | 3.3/10.5/13.5/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
