| Varenummer | C070VW02 V1 |
| Mærke | AUO |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | C070VW02 V1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 170.8×107.95×21.5 mm |
| overflade | Antiglare (Haze 40%), Hard coating (3H) |
| lysstyrke | 350 cd/m² (Min.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 20/30 (Max.)(Tr/Td) |
| synsvinkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 4S4PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 98 pins |
| indgangsspænding | 3.3/9.8/15/-7V (Typ.)(VDD/AVDD/VGH/VGL) |
| rohs: | |
| Ansøgning | CNS |
| C070VAN01.1 | AUO | 7.0 | 800×480 |
| C070VTN02.0 | AUO | 7.0 | 800×480 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| C070VVN03.3 | AUO | 7.0 | 800×480 |
| C070VW01 V0 | AUO | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| C070VW04 V2 | AUO | 7.0 | 800×480 |
| C070VW04 V5 | AUO | 7.0 | 800×480 |
| C070VW04 V6 | AUO | 7.0 | 800×480 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| L5F30705T10 | Epson | 5.0 | 400×240 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LQ058Y5DG30A | SHARP | 5.8 | 800×480 |
| LQ088H9DR01U | SHARP | 8.8 | 640×240 |
| LQ6BW506 | SHARP | 5.8 | 400×234 |
| PA050XS7 | E Ink | 5.0 | 320×234 |
| PW100XS5 | E Ink | 10.0 | 640×468 |
