| Varenummer | CLAA088WA01XN |
| Mærke | CPT |
| Størrelse | 8.8 |
| Ansøgning | CNS |
| Løsning | 1280×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA088WA01XN |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.8 inch |
| løsning | 1280(RGB)×480 , DVGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 209.28×78.48 mm |
| omrids | 229.6×97.3×6.3 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S14PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 60 pins |
| indgangsspænding | 3.3/13.0/20/-6.0V (Typ.)(DVDD/AVDD/IGH/IGL) |
| Ansøgning | CNS |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| CLAA089NA0BCW | CPT | 8.9 | 1024×600 |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| A070VW08 V2 | AUO | 7.0 | 800×480 |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| G070Y2-L01 | Innolux | 7.0 | 800×480 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| LQ049B5DG04 | SHARP | 4.9 | 320×96 |
| LQ070T5DR02 | SHARP | 7.0 | 480×240 |
| PD040QX1 | E Ink | 4.0 | 320×240 |
