| Varenummer | CM520F1-001 |
| Mærke | CSOT |
| Størrelse | 5.2 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | MIPI |
| panel mærke | CSOT |
| panel model | CM520F1-001 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.2 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 64.8×115.2 mm |
| omrids | 66.4×121.6 mm |
| overflade | Hard coating |
| transmissivitet | 8.3% (Typ.)(with APCF) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | , CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| signal interface | MIPI |
| Ansøgning | MPH |
