| Varenummer | BV045WVM-N00 |
| Mærke | BOE |
| Størrelse | 4.5 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1050:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BV045WVM-N00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.5 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 58.752×97.92 mm |
| omrids | 62.65×107.72×1.78 mm |
| overflade | Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1050:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193152% |
| responstid | 12.5/12.5 (Typ.)(Tr/Td); 40 (Typ.)(G to G) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 30 pins |
| Ansøgning | MPH |
