| Varenummer | HVA37WV1-M02 |
| Mærke | HYDIS |
| Størrelse | 3.7 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | HYDIS |
| panel model | HVA37WV1-M02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.7 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 48.24×80.4 mm |
| omrids | 52.54×89.5 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193171% |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 8S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 54 pins |
| indgangsspænding | 1.8/3.0V (Typ.)(IOVCC/VCC) |
| Ansøgning | MPH |
