| Varenummer | LH550WF2-SD03 |
| Mærke | LG Display |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 460 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LH550WF2-SD03 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 5.5 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | AH3-IPS, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.94×128.01×1.55 mm |
| overflade | |
| lysstyrke | 460 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 50 pins |
| indgangsspænding | 1.8/5.0/-5.0V (Typ.)(VDD/VAN/VPG) |
| Ansøgning | MPH |
