| Varenummer | DLC0350FVG-5 |
| Mærke | Other |
| Størrelse | 3.5 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 350:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Parallel/Serial |
| panel mærke | DLC |
| panel model | DLC0350FVG-5 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.9×64×3.25 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 50 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | DSC |
| A024CN02 VJ | AUO | 2.4 | 480×234 |
| A027DTN01.3 | AUO | 2.7 | 320×240 |
| A030DW01 V1 | AUO | 3.0 | 320×240 |
| CLAA030HA22DE | CPT | 3.0 | 960×480(dot) |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| FX020410DNSWBG01 | Data Image | 2.4 | 480×234 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LS027T3DG01 | SHARP | 2.7 | 320×240 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
