| Varenummer | LS027T3DG01 |
| Mærke | SHARP |
| Størrelse | 2.7 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | SHARP |
| panel model | LS027T3DG01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 2.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 59.49×33.48 mm |
| omrids | 65×45 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30/50 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 45 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DSC |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| A027DN03 V1 | AUO | 2.7 | 320×240 |
| A030DW01 V0 | AUO | 3.0 | 320×240 |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| DLC0350FVG-5 | Other | 3.5 | 320×240 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LS025A8DZ01S | SHARP | 2.5 | 320×240 |
| LTV250QV-F03 | Samsung | 2.5 | 320×240 |
| PA025XSB | E Ink | 2.5 | 480×234 |
| TD030MHEB3 | TPO | 3.0 | 320×240 |
