| Varenummer | DMF6104NF-FW |
| Mærke | Kyocera |
| Størrelse | 5.3 |
| Ansøgning | IA |
| Løsning | 256×128 |
| Sammensætning | LCM |
| Lysstyrke | 50 |
| CR | 15:1 |
| Farver | Monochrome |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | OPTREX |
| panel model | DMF6104NF-FW |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 5.3 inch |
| løsning | 256×128 |
| visningstilstand | STN, Black/White (Negative), Transmissive |
| aktivt område | 120.32×60.16 mm |
| omrids | 167×116 mm |
| overflade | |
| lysstyrke | 50 cd/m² (Min.) |
| kontrastforhold | 15:1 (Typ.) |
| vise farver | Monochrome |
| responstid | 110/160 (Typ.)(Tr/Td) |
| synsvinkel | |
| frekvens | 70Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (4-bit), 16 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
