| Varenummer | LH530WX1-SH02 |
| Mærke | LG Display |
| Størrelse | 5.3 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 900:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | LG Display |
| panel model | LH530WX1-SH02 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.3 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | AH3-IPS, Normally Black, Transmissive |
| aktivt område | 65.45×116.35 mm |
| omrids | 68.048×123.652×0.3 mm |
| overflade | |
| glas dybde | 0.15+0.15 mm |
| transmissivitet | 3.5% (Typ.)(with Polarizer) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | , CIE193174% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | COG Suggest HX8394-A01, NT33520, NT35521, OTM1283A, OTM1288A |
