| Varenummer | EL160.80.50 |
| Mærke | Lumineq |
| Størrelse | 3.5 |
| Ansøgning | IA |
| Løsning | 160×80 |
| Sammensætning | EL |
| Lysstyrke | 80 |
| CR | 50:1 |
| Farver | Mono(Yellow) |
| Baggrundsbelysning | self |
| Interface | Parallel Data |
| panel mærke | Lumineq |
| panel model | EL160.80.50 |
| paneltype | EL , EL |
| panelstørrelse | 3.5 inch |
| løsning | 160×80 |
| aktivt område | 79.9×39.9 mm |
| omrids | 108.9×57.2 mm |
| overflade | |
| lysstyrke | 80 cd/m² (Typ.) |
| kontrastforhold | 50 : 1 (Typ.) |
| vise farver | Mono(Yellow) (1-bit) |
| synsvinkel | 89/89/89/89 (Typ.)(L/R/U/D) |
| frekvens | 240Hz |
| signal interface | Parallel Data (1ch, 4-bit), 20 pins |
| indgangsspænding | 5/12V (Typ.)(VL/VH) |
| Ansøgning | IA |
