| Varenummer | EJ080NA-05A |
| Mærke | Innolux |
| Størrelse | 8.0 |
| Ansøgning | DPF |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 500:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CHIMEI INNOLUX |
| panel model | EJ080NA-05A 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 162×121.5 mm |
| omrids | 183×141×5.9 mm |
| overflade | Antiglare |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Dithering) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S9PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3/10.4/16.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | DPF |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| BP080WX7-100 | BOE | 8.0 | 1280×800 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| EJ080NA-04B | Innolux | 8.0 | 1024×768 |
| EJ080NA-04C | Innolux | 8.0 | 1024×768 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| EJ080NA-05B | Innolux | 8.0 | 800×600 |
| HSD080IFW1-A00 | HannStar | 8.0 | 1024×600 |
| PD080SL2 | E Ink | 8.0 | 800×600 |
| TM080SDH01 | Tianma | 8.0 | 800×600 |
| AT070TN01 | Innolux | 7.0 | 480×234 |
| AT070TN90 | Innolux | 7.0 | 800×480 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| AT102TN03 V.9 | Innolux | 10.2 | 800×480 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| HSD100IFW1-F01 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LQ070Y3DG04 | SHARP | 7.0 | 800×480 |
| P64AN2WP02 | E Ink | 6.4 | 320×234 |
