| Varenummer | LB070WV1-TD12 |
| Mærke | LG Display |
| Størrelse | 7.0 |
| Ansøgning | DPF |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | LG.Philips LCD |
| panel model | LB070WV1-TD12 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 167×104.6×5.8 mm |
| overflade | Antiglare |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 50 pins |
| indgangsspænding | 3.3/12.0/3.3V (Typ.)(VCC/VDD/DVCC) |
| Ansøgning | DPF |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LB070WQ4-TM01 | LG Display | 7.0 | 480×234 |
| LB070WQ4-TM06 | LG Display | 7.0 | 480×234 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD12 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| A080SN03 V3 | AUO | 8.0 | 800×600 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
| HSD070ISN1-D00 | HannStar | 7.0 | 800×600 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
| PM102WX1 | E Ink | 10.2 | 800×480 |
| PW070XU3 | E Ink | 7.0 | 480×234 |
