| Varenummer | BP080WX7-100 |
| Mærke | BOE |
| Størrelse | 8.0 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BP080WX7-100 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 8.0 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 172.224×107.64 mm |
| omrids | 179.6×116.9×0.793 mm |
| overflade | Hard coating (3H) |
| glas dybde | 0.25+0.25 mm |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193155% |
| responstid | 24 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
