| Varenummer | EL640.480-A4 SBS |
| Mærke | PLANAR |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | EL |
| Lysstyrke | 55 |
| CR | |
| Farver | Grayscale |
| Baggrundsbelysning | self |
| Interface | Parallel Data |
| panel mærke | PLANAR |
| panel model | EL640.480-A4 SBS |
| paneltype | EL , EL |
| panelstørrelse | 10.4 inch |
| løsning | 640×480 , VGA |
| aktivt område | 211.1×158.3 mm |
| omrids | 263×192 mm |
| overflade | |
| lysstyrke | 55 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | Grayscale (4-bit) |
| synsvinkel | |
| frekvens | 60Hz |
| signal interface | Parallel Data (4-bit), 40 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | IA |
