| Varenummer | EPW1802AA |
| Mærke | Futaba |
| Størrelse | 1.8 |
| Ansøgning | SB |
| Løsning | 160×32 |
| Sammensætning | OLED |
| Lysstyrke | 600 |
| CR | 10000:1 |
| Farver | Grayscale(W) |
| Baggrundsbelysning | self |
| Interface | SPI |
| panel mærke | Futaba |
| panel model | EPW1802AA 1 Compatible model |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 1.8 inch |
| løsning | 160×32 |
| aktivt område | 45.096×9 mm |
| omrids | 55.3×14.94×0.246 mm |
| overflade | Without Polarizer |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Min.) |
| vise farver | Grayscale(W) (4-bit) |
| synsvinkel | |
| frekvens | 100Hz |
| driver ic | Built-in SSD1362 |
| signal interface | SPI, 13 pins |
| indgangsspænding | 1.8/12.0V (Typ.)(VCI/VCC) |
| Ansøgning | SB |
| EPW1802AA | Futaba | 1.8 | 160×32 |
| ES063TC1 | E Ink | 6.3 | 200×1040 |
| NVK16BSC001G-C-0000 | Neoview Kolon | 1.7 | 80×168 |
| OEL9M0068-G-E | Other | 0.91 | 128×32 |
| OEL9M0068-R-E | Other | 0.91 | 128×32 |
| OEL9M0068-W-E | Other | 0.91 | 128×32 |
| OEL9M0068-Y-E | Other | 0.91 | 128×32 |
| RGC05072032WR000 | RiTdisplay | 0.48 | 72×32 |
| UG-2832HSWEG04 | WiseChip | 0.91 | 128×32 |
| UG-2832KLBEG04 | WiseChip | 0.91 | 128×32 |
