| Varenummer | UG-2832KLBEG04 |
| Mærke | WiseChip |
| Størrelse | 0.91 |
| Ansøgning | SB |
| Løsning | 128×32 |
| Sammensætning | OLED |
| Lysstyrke | 150 |
| CR | 10000:1 |
| Farver | Mono(Blue) |
| Baggrundsbelysning | self |
| Interface | SPI |
| panel mærke | WiseChip |
| panel model | UG-2832KLBEG04 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 0.91 inch |
| løsning | 128×32 |
| aktivt område | 22.384×5.584 mm |
| omrids | 31.66×11.5×1.55 mm |
| overflade | Antiglare |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 10000 : 1 (Typ.) |
| vise farver | Mono(Blue) |
| synsvinkel | |
| driver ic | COG Built-in SSD1306 |
| signal interface | 4-wire SPI, 15 pins |
| indgangsspænding | 2.8/7.5V (Typ.)(VDD/VCC) |
| Ansøgning | SB |
