| Varenummer | RGC05072032WR000 |
| Mærke | RiTdisplay |
| Størrelse | 0.48 |
| Ansøgning | SB |
| Løsning | 72×32 |
| Sammensætning | OLED |
| Lysstyrke | 330 |
| CR | 2000:1 |
| Farver | Mono(White) |
| Baggrundsbelysning | self |
| Interface | SPI |
| panel mærke | RiTdisplay |
| panel model | RGC05072032WR000 |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 0.48 inch |
| løsning | 72×32 |
| aktivt område | 11.212×4.972 mm |
| omrids | 14.9×11.29×1.26 mm |
| overflade | Antiglare |
| lysstyrke | 330 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | Mono(White) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 105Hz |
| driver ic | COG Built-in SPD0301 |
| signal interface | SPI, 11 pins |
| indgangsspænding | 12.0/2.8V (Typ.)(VCC/VDD) |
| Ansøgning | SB |
