| Varenummer | G185BGE-L01 |
| Mærke | Innolux |
| Størrelse | 18.5 |
| Ansøgning | IA |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | G185BGE-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 409.8×230.4 mm |
| omrids | 430.37×254.6×16.6 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 1.5/3.5 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
| G185BGE-L01 | Innolux | 18.5 | 1366×768 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| HT185WX1-300 | BOE | 18.5 | 1366×768 |
| LM185TT2A | PANDA | 18.5 | 1366×768 |
| LM185WH1-TLA1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLF1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| M185B1-L07 | Innolux | 18.5 | 1366×768 |
| V185B1-LE1 | Innolux | 18.5 | 1366×768 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| HT150X02-101 | BOE | 15.0 | 1024×768 |
| KCG075VG2BE-G00 | Kyocera | 7.5 | 640×480 |
| MC57T04L | Other | 5.7 | 320×240 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL6448BC33-20 | NLT | 10.4 | 640×480 |
| NL8060BC31-27D | NLT | 12.1 | 800×600 |
| NL8060BC31-47 | NLT | 12.1 | 800×600 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
