| Varenummer | KCG075VG2BE-G00 |
| Mærke | Kyocera |
| Størrelse | 7.5 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 30:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Kyocera |
| panel model | KCG075VG2BE-G00 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 7.5 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 151.68×113.76 mm |
| omrids | 184×139.8×13.2 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 30:1 (Typ.) |
| vise farver | Color |
| responstid | 270/280 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 2 pcsCCFLOptional |
| signal interface | Parallel Data (8-bit), 20 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD) |
| rohs: | |
| Ansøgning | IA |
