| Varenummer | G190SVT01.0 |
| Mærke | AUO |
| Størrelse | 19.0 |
| Ansøgning | IA |
| Løsning | 1680×342 |
| Sammensætning | LCM |
| Lysstyrke | 260 |
| CR | 2000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | G190SVT01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch(1/3 cut of 22.0") |
| løsning | 1680(RGB)×342 |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 473.76×96.44 mm |
| omrids | 497.7×126.8×21.66 mm |
| overflade | Antiglare, Hard coating (7H) |
| lysstyrke | 260 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193168% |
| responstid | 8 (Typ.)(G to G); 20 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S5PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
