| Varenummer | NL128102BM29-05A |
| Mærke | NLT |
| Størrelse | 19.0 |
| Ansøgning | MD |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 900:1 |
| Farver | Grayscale |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL128102BM29-05A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1280(LCR)×1024 , SXGA |
| visningstilstand | SA-SFT, Normally Black, Transmissive |
| aktivt område | 376.32×301.056 mm |
| omrids | 404.2×330×25.55 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | Grayscale (8-bit) |
| responstid | 18/17 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| rohs: | |
