| Varenummer | HGS128645-Y-EH-LV |
| Mærke | Other |
| Størrelse | 2.7 |
| Ansøgning | IA |
| Løsning | 128×64 |
| Sammensætning | OLED |
| Lysstyrke | 100 |
| CR | 2000:1 |
| Farver | Mono(Yellow) |
| Baggrundsbelysning | self |
| Interface | CPU/SPI |
| panel mærke | TSINGTEK |
| panel model | HGS128645-Y-EH-LV |
| paneltype | PM-OLED , OLED |
| panelstørrelse | 2.7 inch |
| løsning | 128×64 |
| aktivt område | 61.41×30.69 mm |
| omrids | 75×53.5×7 mm |
| overflade | |
| lysstyrke | 100 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | Mono(Yellow) |
| synsvinkel | 80/80/80/80 (Min.)(L/R/U/D) |
| driver ic | Built-in SSD1325 |
| signal interface | 8-bit 6800/8080 parallel, SPI, 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
| Ansøgning | IA |
