| Varenummer | AA104SG01 |
| Mærke | Mitsubishi |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA104SG01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 243×181.6×12.7 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| responstid | 6/19 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA104SG01 | Mitsubishi | 10.4 | 800×600 |
| AA104SH02--T1 | Mitsubishi | 10.4 | 800×600 |
| AA104SL02-DE1 | Mitsubishi | 10.4 | 800×600 |
| AA104VC01 | Mitsubishi | 10.4 | 640×480 |
| AA104VC02 | Mitsubishi | 10.4 | 640×480 |
| AA104VC06 | Mitsubishi | 10.4 | 640×480 |
| AA104XD02 | Mitsubishi | 10.4 | 1024×768 |
| AA104XD12 | Mitsubishi | 10.4 | 1024×768 |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| AA10SA6C-ADDD | Mitsubishi | 10.4 | 800×600 |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| BA104S01-200 | BOE | 10.4 | 800×600 |
| CLAA057VC01CW | CPT | 5.7 | 640×480 |
| EDMGRB8KHF | Panasonic | 7.8 | 640×480 |
| EL160.80.50 | Lumineq | 3.5 | 160×80 |
| LB104V03-TD01 | LG Display | 10.4 | 640×480 |
| LM64P10 | SHARP | 7.2 | 640×480 |
| LQ190E1LW01 | SHARP | 19.0 | 1280×1024 |
| PD064VX1 | E Ink | 6.4 | 640×480 |
| PD104VT1 | E Ink | 10.4 | 640×480 |
