| Varenummer | HSD070PFW3-D00 |
| Mærke | HannStar |
| Størrelse | 7.0 |
| Ansøgning | MP4 |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | HannStar |
| panel model | HSD070PFW3-D00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 153.6×90 mm |
| omrids | 167.25×104.65×3 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193150% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/70/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S5PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 31 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | MP4 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| HSD070PFW1-A00 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| HSD070PFW3-D00 | HannStar | 7.0 | 1024×600 |
| HSD070PWW1-B01 | HannStar | 7.0 | 1280×800 |
| HSD070PWW1-C00 | HannStar | 7.0 | 1280×800 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| LD070WS2-SL04 | LG Display | 7.0 | 1024×600 |
| A070VW08 V0 | AUO | 7.0 | 800×480 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| BA070WS1-402 | BOE | 7.0 | 1024×600 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| CLAA070ND23CW | CPT | 7.0 | 1024×600 |
| DLC0700JMG-6 | Other | 7.0 | 1024×600 |
| EE070NA-01D | Innolux | 7.0 | 1024×600 |
| EJ070NA-01F | Innolux | 7.0 | 1024×600 |
| LMS430HF11-003 | Samsung | 4.3 | 480×272 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
