| Varenummer | HSD101PWW1-G10 |
| Mærke | HannStar |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | HannStar |
| panel model | HSD101PWW1-G10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | HS-IPS, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 227.42×147.69×4.25 mm |
| overflade | Hard coating |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| HSD101PFW1-A01 | HannStar | 10.1 | 1024×576 |
| HSD101PFW1-B00 | HannStar | 10.1 | 1024×576 |
| HSD101PFW2-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-B00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-F01 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LP094WX1-SLA1 | LG Display | 9.4 | 1280×800 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| N070ICE-G02 Rev.C3 | Innolux | 7.0 | 800×1280 |
| N070ICN-GB1 | Innolux | 7.0 | 800×1280 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
