| Varenummer | VVX10T022N00 |
| Mærke | Panasonic |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 2560×1600 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Panasonic |
| panel model | VVX10T022N00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 2560(RGB)×1600 , WQXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 227.65×147.85×4.37 mm |
| overflade | Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S6PWLEDWithout Driver |
| signal interface | eDP (4 Lanes), 51 pins |
| indgangsspænding | 3.7V (Typ.) |
| Ansøgning | PAD |
