| Varenummer | HSD190ME13-A13 |
| Mærke | HannStar |
| Størrelse | 19.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 700:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | HannStar |
| panel model | HSD190ME13-A13 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 376.32×301.056 mm |
| omrids | 396×324×18 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC) |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/75/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| HSD190ME12-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190ME12-A10 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-A13 | HannStar | 19.0 | 1280×1024 |
| HSD190ME13-D10 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A01 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN4-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN4-A03 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| LM170E01-TLBF | LG Display | 17.0 | 1280×1024 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM190E02-A4 | LG Display | 19.0 | 1280×1024 |
| LM220WE4-SLB1 | LG Display | 22.0 | 1680×1050 |
| LM270WQ1-SDC2 | LG Display | 27.0 | 2560×1440 |
| LQ150X1DWF1 | SHARP | 15.0 | 1024×768 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM190E1-L03 | Samsung | 19.0 | 1280×1024 |
| LTM215HL01 | Samsung | 21.5 | 1920×1080 |
| LTM300M1-P02 | Samsung | 30.0 | 2560×1600 |
