| Varenummer | LTM215HL01 |
| Mærke | Samsung |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTM215HL01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 476.064×267.786 mm |
| omrids | 497.6×292.2×11 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 16S2PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM215WF3-SDC2 | LG Display | 21.5 | 1920×1080 |
| LTM213U3-L07 | Samsung | 21.3 | 1600×1200 |
| LTM213U4-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L01 | Samsung | 21.3 | 1600×1200 |
| LTM213U6-L02 | Samsung | 21.3 | 1600×1200 |
| LTM215HL01 | Samsung | 21.5 | 1920×1080 |
| LTM215HT03 | Samsung | 21.5 | 1920×1080 |
| LTM215HT04 | Samsung | 21.5 | 1920×1080 |
| LTM215HT05 | Samsung | 21.5 | 1920×1080 |
| T215HVN01.1 | AUO | 21.5 | 1920×1080 |
| HR215WU1-210 | BOE | 21.5 | 1920×1080 |
| LM185WH1-TLF4 | LG Display | 18.5 | 1366×768 |
| LM230WFA-SLZ1 | LG Display | 23.0 | 1920×1080 |
| LM240WU7-SLA1 | LG Display | 24.0 | 1920×1200 |
| LTM185AT05 | Samsung | 18.5 | 1366×768 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| NL10276AC30-03 | NLT | 15.0 | 1024×768 |
| NL256204AM15-02A | NLT | 20.1 | 2560×2048 |
