| Varenummer | LTM300M1-P02 |
| Mærke | Samsung |
| Størrelse | 30.0 |
| Ansøgning | DMPC |
| Løsning | 2560×1600 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | TMDS |
| panel mærke | SAMSUNG |
| panel model | LTM300M1-P02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 30.0 inch |
| løsning | 2560(RGB)×1600 , WQXGA |
| visningstilstand | S-PVA, Normally Black, Transmissive |
| aktivt område | 641.28×400.8 mm |
| omrids | 677.3×436.8 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| responstid | 12 (Typ.)(Tr+Td); 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 16 pcsCCFLEmbedded (Inverter) |
| signal interface | Dual Link TMDS, 45 pins |
| indgangsspænding | 18.0V (Typ.) |
| Ansøgning | DMPC |
