| Varenummer | HX104X02-100 |
| Mærke | HYDIS |
| Størrelse | 10.4 |
| Ansøgning | PAD |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 340 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | HYDIS |
| panel model | HX104X02-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | AFFS+, Normally Black, Transmissive |
| aktivt område | 210.4×157.8 mm |
| omrids | 238.6×173.2×6.8 mm |
| overflade | Antiglare, Antireflection |
| lysstyrke | 340 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193140% |
| responstid | 36 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| A104SN01 V0 | AUO | 10.4 | 800×600 |
| HX104X01-210 | HYDIS | 10.4 | 1024×768 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| HX104X02-100 | HYDIS | 10.4 | 1024×768 |
| LM104VC1T51 | SHARP | 10.4 | 640×480 |
| LQ104V1LG81 | SHARP | 10.4 | 640×480 |
| NL6448AC33-18 | NLT | 10.4 | 640×480 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| PD104SLD | E Ink | 10.4 | 800×600 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| BP070WS1-102 | BOE | 7.0 | 1024×600 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| CLAA101WJ06 | CPT | 10.1 | 1366×768 |
| HSD101PWW1-G10 | HannStar | 10.1 | 1280×800 |
| LP097X02-SLQE | LG Display | 9.7 | 1024×768 |
| LQ070M1SX01 | SHARP | 7.0 | 1200×1920 |
| LQ097L1JY02Z | SHARP | 9.7 | 2048×1536 |
| LTL090CL01-W02 | Samsung | 9.0 | 1920×1280 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
