| Varenummer | B116XAN01.0 |
| Mærke | AUO |
| Størrelse | 11.6 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | B116XAN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 256.125×144 mm |
| omrids | 267.17×157.31×4.74 mm |
| overflade | |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Min.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S6PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 45 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
