| Varenummer | IAQX10N |
| Mærke | IDTech |
| Størrelse | 15.0 |
| Ansøgning | NBPC |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 150 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | IDTech |
| panel model | IAQX10N |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 2048(RGB)×1536 , QXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 304.1×228.1 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | 150 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 30/30 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFL |
| signal interface | LVDS (2 ch, 6-bit) |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
