| Varenummer | IAQX10M |
| Mærke | IDTech |
| Størrelse | 15.0 |
| Ansøgning | DMPC |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | IDTech |
| panel model | IAQX10M |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 2048(RGB)×1536 , QXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 304.1×228.1 mm |
| omrids | 326×244.5×13.3 mm |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 30/30 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DMPC |
