| Varenummer | ITSX88E |
| Mærke | IDTech |
| Størrelse | 18.1 |
| Ansøgning | MD |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 550:1 |
| Farver | Grayscale |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | IDTech |
| panel model | ITSX88E 0 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 18.1 inch |
| løsning | 1280(LCR)×1024 , SXGA |
| visningstilstand | DD-IPS, Normally Black, Transmissive |
| aktivt område | 359.04×287.232 mm |
| omrids | 389×317.2 mm |
| overflade | |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 550:1 (Typ.) |
| vise farver | Grayscale (8-bit) |
| responstid | 40 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
| IAUX61 | IDTech | 19.6 | 1600×1200 |
| ITSX88E | IDTech | 18.1 | 1280×1024 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| NL128102BM29-05A | NLT | 19.0 | 1280×1024 |
| NL160120AC27-32B | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| R208R3-L01 | Innolux | 20.8 | 2048×1536 |
| R213RFE-L01 | Innolux | 21.3 | 2048×1536 |
| R213T3-L02 | Innolux | 21.3 | 2560×2048 |
| VVX21F136J00 | Panasonic | 21.3 | 1600×1200 |
