| Varenummer | NL160120AC27-32B |
| Mærke | NLT |
| Størrelse | 21.3 |
| Ansøgning | MD |
| Løsning | 1600×1200 |
| Sammensætning | LCM |
| Lysstyrke | 760 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | NEC |
| panel model | NL160120AC27-32B |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.3 inch |
| løsning | 1600(RGB)×1200 , UXGA |
| visningstilstand | UA-SFT, Normally Black, Transmissive |
| aktivt område | 432×324 mm |
| omrids | 457×350×23 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 760 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
