| Varenummer | R208R3-L01 |
| Mærke | Innolux |
| Størrelse | 20.8 |
| Ansøgning | MD |
| Løsning | 2048×1536 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | R208R3-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 20.8 inch |
| løsning | 2048(RGB)×1536 , QXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 423.9×318 mm |
| omrids | 457×350×45.8 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 10/10 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 14 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (4 ch, 8-bit), 70 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | MD |
| ITQX21G | IDTech | 20.8 | 2048×1536 |
| LB190E01-SL01 | LG Display | 19.0 | 1280×1024 |
| NL160120BM27-07 | NLT | 21.3 | 1600×1200 |
| NL160120BM27-07A | NLT | 21.3 | 1600×1200 |
| NL204153BM21-05A | NLT | 21.3 | 2048×1536 |
| R196U2-L01 | Innolux | 19.6 | 1600×1200 |
| R208R3-L01 | Innolux | 20.8 | 2048×1536 |
| R300M1-L01 | Innolux | 30.0 | 4096×2560 |
| R300SFE-L02 | Innolux | 30.0 | 3280×2048 |
| VVX28T143H00 | Panasonic | 28.0 |
