| Varenummer | KCB084SV1AC-G40 |
| Mærke | Kyocera |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 30:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Kyocera |
| panel model | KCB084SV1AC-G40 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 170.4×127.8 mm |
| omrids | 205.1×145 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 30:1 (Typ.) |
| vise farver | Color |
| responstid | 300/250 (Typ.)(Tr/Td) |
| synsvinkel | 55/50/35/20 (Typ.)(CR≥2)(L/R/U/D) |
| lampe type | 1 pcsCCFL |
| signal interface | Parallel Data (8-bit), 31 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
