| Varenummer | LB121S02-A2 |
| Mærke | LG Display |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 200:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | LG.Philips LCD |
| panel model | LB121S02-A2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 280×218×11.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 200:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 20/35 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 41 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | IA |
| AA121XN01 | Mitsubishi | 12.1 | 1024×768 |
| LB121S02-A2 | LG Display | 12.1 | 800×600 |
| LB121S03-TD01 | LG Display | 12.1 | 800×600 |
| LB121S03-TL01 | LG Display | 12.1 | 800×600 |
| LB121S03-TL02 | LG Display | 12.1 | 800×600 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LB121S03-TL04 | LG Display | 12.1 | 800×600 |
| LB121S1-A2 | LG Display | 12.1 | 800×600 |
| LQ121S1DG21 | SHARP | 12.1 | 800×600 |
| TCG121XGLPAPNN-AN20 | Kyocera | 12.1 | 1024×768 |
| AA084VG01 | Mitsubishi | 8.4 | 640×480 |
| AC150XA01 | Mitsubishi | 15.0 | 1024×768 |
| DMF-50174ZNB-FW | Kyocera | 5.7 | 320×240 |
| EL640.480-AAA | PLANAR | 10.4 | 640×480 |
| G170J1-LE1 | Innolux | 17.0 | 1920×1200 |
| G238HAN01.0 | AUO | 23.8 | 1920×1080 |
| G260J1-L05 | Innolux | 25.5 | 1920×1200 |
| KCG057QV1DB-G500 | Kyocera | 5.7 | 320×240 |
| TFD60W12 | TOSHIBA | 6.0 | 320×234 |
| UG-2864KLBLG01 | WiseChip | 1.3 | 128×64 |
