| Varenummer | G170J1-LE1 |
| Mærke | Innolux |
| Størrelse | 17.0 |
| Ansøgning | IA |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 2000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | G170J1-LE1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 365.76×228.6 mm |
| omrids | 386.8×250.8×19 mm |
| overflade | Glare (Haze 0%) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 20/9 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
