| Varenummer | LB150X03-TL02 |
| Mærke | LG Display |
| Størrelse | 15.0 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 700:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LB150X03-TL02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 304.128×227.328 mm |
| omrids | 326.5×253.5×12.5 mm |
| overflade | Antiglare |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193172% |
| responstid | 2/6 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/55/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| CLAA150XP03 | CPT | 15.0 | 1024×768 |
| G150XG02 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V3 | AUO | 15.0 | 1024×768 |
| LB150X02-TL01 | LG Display | 15.0 | 1024×768 |
| LB150X03-TL02 | LG Display | 15.0 | 1024×768 |
| LB150X03-TL03 | LG Display | 15.0 | 1024×768 |
| LQ150X1LGN2A | SHARP | 15.0 | 1024×768 |
| NL10276BC30-24D | NLT | 15.0 | 1024×768 |
| T150XG01 V0 | AUO | 15.0 | 1024×768 |
| TM150TCS02 | Tianma | 15.0 | 1024×768 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AA084SD01 | Mitsubishi | 8.4 | 800×600 |
| AA121XJ02 | Mitsubishi | 12.1 | 1024×768 |
| DMF50081NF-SFW | Kyocera | 4.7 | 320×240 |
| DMF6104NF-FW | Kyocera | 5.3 | 256×128 |
| G084SN03 V0 | AUO | 8.4 | 800×600 |
| LQ104V1DG72 | SHARP | 10.4 | 640×480 |
| SG12232A | Other | 2.2 | 122×32 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
| TM057KDH03 | Tianma | 5.7 | 320×240 |
