| Varenummer | T150XG01 V0 |
| Mærke | AUO |
| Størrelse | 15.0 |
| Ansøgning | LCTV |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 500:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | T150XG01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 326.5×253.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193160% |
| responstid | 12/4 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | LCTV |
| LB150X03-TL02 | LG Display | 15.0 | 1024×768 |
| LQ150X1LGN2A | SHARP | 15.0 | 1024×768 |
| LQ150X1LW71U | SHARP | 15.0 | 1024×768 |
| LTN150XB-L02 | Samsung | 15.0 | 1024×768 |
| NA19020-C262 | Fujitsu | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| SVA150XG10TB | SVA-NEC | 15.0 | 1024×768 |
| T150XG01 V0 | AUO | 15.0 | 1024×768 |
| T150XG01 V2 | AUO | 15.0 | 1024×768 |
| TM150XG-A02-01 | SANYO | 15.0 | 1024×768 |
| AX080E002B | KOE | 31.5 | 1366×768 |
| HV460WU2-202 | BOE | 46 | 1920×1080 |
| HV460WUC-200 | BOE | 46 | 1920×1080 |
| LC420EUJ-SGE1 | LG Display | 42 | 1920×1080 |
| LC490EQJ-SGK1 | LG Display | 49 | 3840×2160 |
| T320HVN01.2 | AUO | 31.5 | 1920×1080 |
| V236BJ1-P01 | Innolux | 23.6 | 1366×768 |
| V260B2-L01 | Innolux | 26.0 | 1366×768 |
| V420HK1-LS5 Rev.C7 | Innolux | 42 | 1920×1080 |
| V500HK1-LS6 Rev.C7 | Innolux | 50 | 1920×1080 |
