| Varenummer | LC170WXN-SAA1 |
| Mærke | LG Display |
| Størrelse | 17.0 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | EEFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LC170WXN-SAA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 372.918×209.664 mm |
| omrids | 413×252 mm |
| overflade | Antiglare (Haze 13%), Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8/9 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8 pcsEEFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
