| Varenummer | HT17E12-210 |
| Mærke | HYDIS |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 430:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | HYUNDAI |
| panel model | HT17E12-210 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 337.92×270.336 mm |
| omrids | 358.5×296.5×17.5 mm |
| overflade | |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 430:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC) |
| responstid | 5/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/65/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| G170EG01 V0 | AUO | 17.0 | 1280×1024 |
| G170J1-LE1 | Innolux | 17.0 | 1920×1200 |
| HT17E12-210 | HYDIS | 17.0 | 1280×1024 |
| LM170E01-TLA1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLJ5 | LG Display | 17.0 | 1280×1024 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| M170E5-L08 | Innolux | 17.0 | 1280×1024 |
| M170EG01 VD | AUO | 17.0 | 1280×1024 |
| M170EU01 V0 | AUO | 17.0 | 1280×1024 |
| M170XW01 V3 | AUO | 17.0 | 1280×768 |
| LM170E03-TLH1 | LG Display | 17.0 | 1280×1024 |
| LM170E03-TLL2 | LG Display | 17.0 | 1280×1024 |
| LM201U05-SLA3 | LG Display | 20.1 | 1600×1200 |
| LM240WU7-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSA1 | LG Display | 27.0 | 1920×1080 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| LTM340YP01 | Samsung | 34 | 3440×1440 |
| M190EN04 V1 | AUO | 19.0 | 1280×1024 |
| NL128102BC23-03 | NLT | 15.4 | 1280×1024 |
