| Varenummer | LD070WU2-SM01 |
| Mærke | LG Display |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | QLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LD070WU2-SM01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 104.52×161.87×2.4 mm |
| overflade | Hard coating |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S6PQLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 3.7/1.8V (Typ.)(VSYS/VDD) |
| Ansøgning | PAD |
