| Varenummer | LH470WX6-SD02 |
| Mærke | LG Display |
| Størrelse | 4.7 |
| Ansøgning | MPH |
| Løsning | 750×1334 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | |
| panel mærke | LG Display |
| panel model | LH470WX6-SD02 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.7 inch |
| løsning | 750(RGB)×1334 , WXGA |
| visningstilstand | AH3-IPS, Normally Black, Transmissive |
| aktivt område | 58.5×104.052 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLED |
| Ansøgning | MPH |
| DMF5003NF-FW | Kyocera | 4.7 | 160×128 |
| DMF50081NB-FW | Kyocera | 4.7 | 320×240 |
| G321EV5R000 | SII | 4.7 | 320×240 |
| LH470WX6-SD01 | LG Display | 4.7 | 750×1334 |
| LH470WX6-SD02 | LG Display | 4.7 | 750×1334 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LM32010P | SHARP | 4.7 | 320×240 |
| LQ047K3SX06 | SHARP | 4.7 | 720×1280 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
| ACX425AKM | SONY | 3.7 | 480×800 |
| GCX141AKM-E | SONY | 3.2 | 240×400 |
| LH470WX6-SD01 | LG Display | 4.7 | 750×1334 |
| LH520WF1-SD01 | LG Display | 5.2 | 1080×1920 |
| LMS220GF08 | Samsung | 2.2 | 240×320 |
| LS026Q7UX01 | SHARP | 2.6 | 320×240 |
| LT042MDV5000 | JDI | 4.2 | 768×1280 |
| TD025THEB5 | TPO | 2.5 | 320×240 |
| TD028STEB1 | TPO | 2.8 | 240×320 |
| UG-2828GDEDF11 | WiseChip | 1.5 | 128×128 |
