| Varenummer | LH520WF1-SD01 |
| Mærke | LG Display |
| Størrelse | 5.2 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | Assembly |
| Lysstyrke | 380 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LH520WF1-SD01 |
| paneltype | LTPS TFT-LCD , Assembly |
| panelstørrelse | 5.2 inch |
| løsning | 1080(RGB)×1920 , FHD |
| aktivt område | 64.8×115.2 mm |
| omrids | 69.4×136.4×2.47 mm |
| overflade | Clear |
| lysstyrke | 380 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | MIPI (4 data lanes), 30 pins |
| indgangsspænding | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | MPH |
