| Varenummer | LM18WGSBZ05 |
| Mærke | SHARP |
| Størrelse | 1.8 |
| Ansøgning | MPH |
| Løsning | 120×160 |
| Sammensætning | LCM |
| Lysstyrke | 70 |
| CR | 40:1 |
| Farver | Color |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | SHARP |
| panel model | LM18WGSBZ05 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 1.8 inch |
| løsning | 120(RGB)×160 , QQVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 26.988×35.985 mm |
| omrids | 35.13×55.46 mm |
| overflade | |
| lysstyrke | 70 cd/m² (Typ.) |
| kontrastforhold | 40:1 (Typ.) |
| vise farver | Color |
| responstid | 170/100 (Typ.)(Tr/Td) |
| synsvinkel | 20/35/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| lampe type | 3 pcsWLEDWithout Driver |
| signal interface | 16-bit 8080 parallel, 40 pins |
| indgangsspænding | 2.85V (Typ.) |
| Ansøgning | MPH |
