| Varenummer | BS055FHE-N30-6Q00 |
| Mærke | BOE |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | BOE |
| panel model | BS055FHE-N30-6Q00 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.5 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 69.84×127.16 mm |
| overflade | |
| transmissivitet | 4.3% (Typ.)(with Polarizer) |
| kontrastforhold | 1400:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | COG Suggest OTM1901A, NT35596 |
| Ansøgning | MPH |
| AMFN888 | Samsung | 3.1 | 480×800 |
| CLAF040LE21 AX | CPT | 4.0 | 480×800 |
| CLAF050LN41 TXX | CPT | 5.0 | 540×960 |
| GCX141AKM-E | SONY | 3.2 | 240×400 |
| H430VL02 V1 | AUO | 4.3 | 480×800 |
| LMS241GF31 | Samsung | 2.4 | 240×320 |
| LMS340KC01-001 | Samsung | 3.4 | 720×480 |
| LQ034J1LX01 | SHARP | 3.4 | 320×480 |
| LS037V7DD06R | SHARP | 3.7 | 480×640 |
| LS059T1SX01 | SHARP | 5.9 | 1080×1920 |
